| SPECIFICATIONS |
| Brand |
Intel |
| Series |
13th Gen Raptor Lake |
| Model |
Core i9-13700K (BX8071513700K) |
| Essentials |
| Vertical Segment |
Desktop |
| Lithography |
Intel 7 |
| Core Arrangement |
8 Performance Cores, 8 Efficiency Cores |
| Cores |
16 |
| Threads |
24 |
| Intel Turbo Boost Max Technology 3.0 Frequency |
5.40GHz |
| Performance-core Max Turbo Frequency |
5.30GHz |
| Efficient-core Max Turbo Frequency |
4.20GHz |
| Performance-core Base Frequency |
3.40GHz |
| Efficient-core Base Frequency |
2.50GHz |
| Cache |
30MB Intel Smart Cache |
| Total L2 Cache |
24MB |
| Processor Base Power |
125W |
| Maximum Turbo Power |
253W |
| TJUNCTION |
100°C |
| Memory |
| Max Memory Supported |
128 GB |
| Memory Types |
Up to DDR5 5600MT/s |
| Up to DDR4 3200MT/s |
| Max Number of Memory Channels |
2 |
| Max Memory Bandwidth |
89.6GB/s |
| Graphics |
| Processor Graphics |
Intel UHD Graphics 770 |
| Graphics Base Frequency |
300 MHz |
| Graphics Max Dynamic Frequency |
1.60GHz |
| Graphics Output |
DisplayPort 1.4a, HDMI 2.1 |
| Execution Units |
32 |
| Max Resolution (HDMI) |
4096 x 2160 @ 60Hz |
| Max Resolution (DP) |
7680 x 4320 @ 60Hz |
| API Support |
DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan |
| Multi-Format Codec Engines |
2 |
| Intel Quick Sync Video Support |
Yes |
| Intel Clear Video HD Technology Support |
Yes |
| Number of Displays Supported |
4 |
| Expansion |
| Direct Media Interface (DMI) Revision |
4 |
| Max Number of DMI Lanes |
8 |
| Scalability |
Single socket |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations |
Up to 1x16 plus 4 lanes | 2x8 plus 4 lanes |
| Max Number of PCI Express Lanes |
20 |
| General |
| Advanced Features |
Intel Gaussian & Neural Accelerator 3.0 |
| Intel Thread Director |
| Intel Deep Learning Boost (Intel DL Boost) |
| Intel Speed Shift Technology |
| Intel Turbo Boost Max Technology 3.0 |
| Intel Turbo Boost Technology 2.0 |
| Intel Hyper-Threading Technology |
| Intel 64 |
| 64-bit Instruction Set |
| Intel SSE4.1, Intel SSE4.2, Intel AVX2 Instruction Set Extensions |
| Idle States |
| Enhanced Intel SpeedStep Technology |
| Thermal Monitoring Technologies |
| Intel Volume Management Device (VMD) |
| Security & Reliability Features |
Intel Standard Manageability (ISM) |
| Intel Control-Flow Enforcement Technology |
| Intel AES New Instructions |
| Secure Key |
| Intel OS Guard |
| Intel Trusted Execution Technology |
| Execute Disable Bit |
| Intel Boot Guard |
| Mode-based Execute Control (MBEC) |
| Intel Stable IT Platform Program (SIPP) |
| Intel Virtualization Technology with Redirect Protection (VT-rp) |
| Intel Virtualization Technology (VT-x) |
| Intel Virtualization Technology for Directed I/O (VT-d) |
| Intel VT-x with Extended Page Tables (EPT) |
| Operating System Support |
Windows 10 64-bit |
| Windows 11 64-bit |
| Linux x86-64 |
| Warranty Information |
| Warranty |
3 Year Warranty |
